Detailed configurations
Chassis CXZ51Q
Hydraulic system
Advantages
Better driving environment
Strict quality inspection
Perfect working performance
Technical Data for Pumping Operation
Chassis CXZ51Q
Hydraulic system
Advantages
Better driving environment
Strict quality inspection
Perfect working performance
No. | Item | Unit | Parameter |
1 | Max. speed | km | 90 |
2 | Min. turning diameter | m | 18.4 |
3 | Brake distance | m | 7 |
4 | Approach angle | ° | 31 |
5 | Departure angle | ° | 12 |
6 | Chassis model | CXZ51Q ( Japan ) | |
7 | Total weight | kg | 28150 |
8 | 1st axle load | kg | 6780 |
9 | 2nd, 3rd axle load | kg | 21220 |
10 | Engine model | 6WF1 | |
11 | Max. Engine power | kW | 287 |
12 | Max. Engine torque | N.m | 1862 |
13 | Max. grade-ability | % | 38 |
14 | Fuel consumption limit | L/100km | 34 |
15 | Outline dimensions (Length´ Width ´Height) | mm | 11990´2490´3900 |
Technical Data for Pumping Operation
No. | Item | Unit | Parameter |
1 | Theoretical output | m3/h | 138/90 |
2 | Max. delivery pressure | MPa | 8.7/13 |
3 | Reach height | m | 37.4 |
4 | Reach depth | m | 23.7 |
5 | Front outrigger transverse span | mm | 7280 |
6 | Rear outrigger transverse span | mm | 6600 |
7 | Outrigger longitudinal span | mm | 6860 |
8 | Delivery pipe diameter | mm | 125 |
9 | Remote control distance | m | 100 |
10 | Placing boom slewing range | ° | 370 |
