JONYANG Excavator JYL619E
Parameters
Bucket capacity: 0.8 CBM (standard)
Operating weight:21000kgs
Detail configuration
Cummins 6B-5.9 engine, 129 kw
Advantages
Good working performance with advanced hydraulic system
Better convenience in maintenance
Better quality and more comfortable for operators with wide cabin
JONYANG Excavator JYL619E Optional parts
Our Service:
* We are 7 years supplier, have good price of JONYANG Excavator JYL619E for sale.
* We supply one year guarantee for all machines.
* We also supply Shantui Bulldozer Spare Parts with good price and quick response.
For more details, specification and catalogues about Shantui Bulldozer,
please contact us, Mob. 008615862203425, Mail: [email protected]
Parameters
Bucket capacity: 0.8 CBM (standard)
Operating weight:21000kgs
Detail configuration
Cummins 6B-5.9 engine, 129 kw
Advantages
Good working performance with advanced hydraulic system
Better convenience in maintenance
Better quality and more comfortable for operators with wide cabin
JONYANG Excavator JYL619E Optional parts
| Model | JONYANG Excavator JYL619E |
|---|---|
| Operating weight (Tons) | 21 |
| Standard bucket capacity (m3) | 0.8 |
| Range of bucket capacity |
|
| Diesel engine manufacturer | Cummins |
| Engine model | 6B5.9 |
| Engine power (kw) | 129 |
| Hydraulic system | |
| Hydraulic flow rate (L/min) | 2X214 |
| Hydraulic pressure (MPa) | 32 |
| Travelling speed (km/h) | 28 |
| Grade climbing capacity (%) | 40% |
| Slewing speed (r/min) | 12.5 |
| Stick digging force (kN) | 90 |
| Bucket digging force (kN) | 120 |
| Overall Length (mm) | 9555 |
| Overall Width (mm) | 2760 |
| Overall Height of Boom (mm) | 3450 |
| Overall Height of Cab (mm) | 3255 |
| Engine Cover Height (mm) | 2685 |
| Counterweight Clearance (mm) | 1435 |
| Ground Clearance (mm) | 400 |
| Upperstructure Width (mm) | 2685 |
| Rear-End Length/Swing Radius (mm) | 2835 |
| Wheelbase (mm) | 2960 |
| Overall Width of Blade (mm) | 2400 |
| Overall Height of Blade (mm) | 630 |
| Front Overhang (mm) | 1345 |
| Overall Width with Outrigger Extended (mm) | 3835 |
| Rear Overhang (mm) | 1095 |
| Strick Length (mm) | 2400 |
| Maximum Cutting Height (mm) | 9585 |
| Maximum Dumping Height (mm) | 6775 |
| Maximum Digging Depth (mm) | 5735 |
| Maximum Reach (mm) | 9445 |
