XCMG  Excavator XE15

Parameters
Bucket capacity: 0.044CBM (standard)
Operating weight:1640kgs
Max digging height:3615mm
Max digging reach: 3915mm

Detail configuration
3TNV82A engine, 16.5/2200 kw/rpm
Hydraulic system

Advantages
Our product adopts the humanized design which results in an easy operation and maintenance.
Because of its small size, this engineering machinery fits in narrow spaces. Its semi-enclosed cab increases the driver's comfort.

Optional parts
Standard configured hydraulic breaker pipes are provided, with optional breaker equipment available.

XCMG  Excavator XE15

Model			XCMG  Excavator XE15
Operating weight		kg	1640
Standard bucket capacity		m³	0.044
Engine	Engine Model	/	3TNV82A
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	×
	Air to air intercooler	/	×
	No. of cylinders	/	3
	Rated power/speed	kw/rpm	16.5/2200
	Max. torque/speed	N.m	86.5/1320
	Displacement	L	1.33
The main performance	Travel speed	km/h	4.4/2.4
	Swing speed	r/min	11
	Max. gradeability	/	30°
	Ground pressure	kPa	23.8
	Max.Bucket digging force	kN	13.9
	Max.arm crowd force	kN	8.8
	Main pump	/	Japan nachi
Hydraulic system	Rate flow of main pump	L/min	2×19.8+14.1
	Max pressure of prime relief valve	MPa	24
	Max pressure of travel system	MPa	21
	Max pressure of swing system	MPa	18
	Max pressure of pilot system	MPa	3.3
	Fuel tank capacity	L	20
Oil capacity	Hydraulic tank capacity	L	29
	Engine lubrication	L	5.5
	A Overall length	mm	3760
Overall dimensions	B Overall width	mm	1080
	C Overall height	mm	2400
	D Overall width of upperstructure	mm	1080
	E Track length	mm	1578
	F Overall width of undercarriage	mm	1080
	G  crawer width	mm	230
	H Dozer black(width/height)	mm	1080×225
	I Tumbler distance	mm	1217
	J Crawer gauge	mm	850
	K Clearance under counter weight	mm	472
	L Ground clearance	mm	180
	M Min.tail swing radius	mm	1190
	A Max. digging height	mm	3615
Working range	B Max. dumping height	mm	2480
	C Max. digging depth	mm	2320
	E Max. vertical wall digging depth	mm	1520
	F Max. digging reach	mm	3915
	G Min. swing radius	mm	1675
	H Max.dozer lifting height	mm	220
	I Max.dozer cutting depth	mm	240
	Angle of arm deflection	Degree	70/50
