SHANTUI Bulldozer SD16

Parameters
Blade capacity 4.5/6.04CBM
Operating weight:17000/17370kgs

 Detail configuration
Shangchai SC11CB184G2B1/ Weichai WD10G178E25 engine, 120/1850 kw/rpm

Advantages
A bulldozer is a heavy piece of earthmoving equipment. It uses a front-mounted dozer blade to push soil forward and create a level surface for construction sites.
Bulldozers are commonly used for road construction, water and electricity engineering, farmland leveling, port building, mining and other engineering conditions.

Our Service:
* We are 7 years supplier, have good price of SHANTUI Motor grader SG21-3 for sale.
* We supply one year guarantee for all machines.
* We also supply Shantui Bulldozer Spare Parts with good price and quick response.

For more details, specification and catalogues about Shantui Bulldozer,
please contact us, Mob. 008615862203425, Mail: [email protected]

SHANTUI Bulldozer SD16

ITEM	UNIT	SD16	SHANTUI Bulldozer SD16
L×W×H (Ripper not included)	mm	5140×3388×3032	5500×3900×3100
Operating weight (Ripper not included)	t	17	16.8
Engine	-	Shangchai SC11CB184G2B1/ Weichai WD10G178E25	Shangchai SC11CB184G2B1/ Weichai WD10G178E25
Rated power	kW/ rpm	120/1850	120/1850
Gradeability	。	30	30
Blade type	-	Straight tilt blade U blade Angle blade	U blade
Blade width	mm	Straight tilt blade 3388×1149 U blade 3556× 3970×1040	3900×1200
Dozing capacity	m3	Straight tilt blade 4.5 U blade 5     Angle blade 4.3	5
Ma× drop below ground of blade	mm	540	530
Lift height of blade	mm	1095	1095
Ripper type	-	Three-shank ripper	Three-shank ripper
Ripping depth of ripper	mm	572	572
Lifting height of ripper	mm	592	592
Number of carriers (each side)	-	2	2
Number of track rollers (each side)	-	6	6
Number of track shoes (each side)	-	37	37
Width of track shoe	mm	510	610
Track gauge	mm	1880	1880
Ground length and ground pressure	mm/ MPa	2430-0.067	2430-0.056
Pitch	mm	203.2	203.2
Forward speed	km/h	0–3.29	0–3.29
		0–5.82	0–5.82
		0–9.63	0–9.63
Reverse speed	km/h	0–4.28	0–4.28
		0–7.59	0–7.59
		0–12.53	0–12.53
Net Engine Output at Rated RPM	-	148HP(110.5KW)
