SHANTUI Bulldozer SD32

Parameters
Blade capacity 10/10CBM
Operating weight:37200/37200kgs

Detail configuration
Cummins NTA855- C360S10 engine, 235/2000 kw/rpm

Advantages
Designed based on user-friendly design philosophy, the crawler bulldozer is easy for maintenance and repair.
Equipped with a hydraulic drive system with hydraulic control technology and an advanced structure, which provides reliable performance and convenient and flexible operation.
Our Service:
* We are 7 years supplier, have good price of SHANTUI Bulldozer SD32 for sale.
* We supply one year guarantee for all machines.
* We also supply Shantui Bulldozer Spare Parts with good price and quick response.

For more details, specification and catalogues about Shantui Bulldozer,
please contact us, Mob. 008615862203425, Mail: [email protected]

SHANTUI Bulldozer SD32

ITEM	UNIT	SD32	SHANTUI Bulldozer SD32
L×W×H (Ripper not included)	mm	6880×4130×3725	6880×4130×3725
Operating weight (Ripper not included)	t	37.2	37.2
Engine	-	CumminsNTA855-C360S10	CumminsNTA855-C360S10
Rated power	kW/rpm	235/2000	235/2000
Gradeability	°	30	30
Blade type	-	Straight tilt bladeSemi-U bladeAngle blade	Straight tilt bladeSemi-U bladeAngle blade
Blade width	mm	Straight tilt blade 4130×1590Semi-U blade 4030×1720Angle blade 5000×1140	Straight tilt blade 4130×1590Semi-U blade4030×1720Angle blade 5000×1140
Dozing capacity	m3	Straight tilt blade 10Semi-U blade 11.9Angle blade 6	Straight tilt blade 10Semi-U blade 11.9Angle blade 6
Ma× drop below ground of blade	mm	560	560
Lift height of blade	mm	1560	1560
Ripper type	-	Single ripperThree-shank ripper	Single ripperThree-shank ripper
Ripping depth of ripper	mm	Single ripper 1250Three-shank ripper 842	Single ripper 1250Three-shank ripper 842
Lifting height of ripper	mm	Single ripper 955Three-shank ripper 883	Single ripper 955Three-shank ripper 883
Number of carriers (each side)	-	2	2
Number of track rollers (each side)	-	7	7
Number of track shoes (each side)	-	41	41
Width of track shoe	mm	560	760
Track gauge	mm	2140	2140
Ground length and ground pressure	mm/MPa	3150-0.105	3150-0.076
Pitch	mm	228.6	228.6
Forward speed	km/h	0–3.6	0–3.6
		0–6.6	0–6.6
		0–11.5	0–11.5
Reverse speed	km/h	0–4.4	0–4.4
		0–7.8	0–7.8
		0–13.5	0–13.5
