SHANTUI Bulldozer SD52-5

Parameters
Blade capacity 18.5CBM
Operating weight:67500kgs

Detail configuration
Cummins QSK19 engine, 392/1800 kw/rpm

Advantages
Designed based on user-friendly design philosophy, the crawler bulldozer is easy for maintenance and repair.
The bulldozer was developed for operation in earth moving projects with tough conditions.

Our Service:
* We are 7 years supplier, have good price of SHANTUI Bulldozer SD52-5 for sale.
* We supply one year guarantee for all machines.
* We also supply Shantui Bulldozer Spare Parts with good price and quick response.

For more details, specification and catalogues about Shantui Bulldozer,
please contact us, Mob. 008615862203425, Mail: [email protected]

 SHANTUI Bulldozer SD52-5

ITEM	UNIT	SHANTUI Bulldozer SD52-5
L×W×H(Ripper not included)	mm	10420×4680×4470 (Ripper included)
Operating weight(Ripper not included)	t	67.5(Ripper included)
Engine	-	Cummins QSK19
Engine Emission standard	-	Euro III
Rated power	kW/rpm	392/1800
Gradeability	°	30
Blade type	-	Semi-U blade
Blade width	mm	4695×2265
Dozing capacity	m3	18.5
Ma× drop below ground of blade	mm	720
Lift height of blade	mm	1660
Ripper type	-	Single ripper
Ripping depthof ripper	mm	1435
Lifting height of ripper	mm	1105
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	7
Number of track shoes (each side)	-	40
Width of track shoe	mm	610
Track gauge	mm	2500
Ground length and ground pressure	mm/MPa	3940-0.138
Pitch	mm	280
Forward speed	km/h	0–3.8
		0–6.8
		0–11.8
Reverse speed	km/h	0–5.1
		0–9.2
		0–15.8
