XCMG Crawler crane QUY55

Max.lifting capacity: 55t
Max.Load moment: 1994KN
Main boom length: 13-52m
Fix jib length: 9.15-15.25m

Detail configuration:
* Shangchai engine
* Hirschmann moment limitor
* Cabin with air conditioner

Optional parts
* Fast hook falling

Crawler cranes are vehicles that travel by a crawler with great lifting capacity and good anti-slip ability.
XCMG is the first Chinese manufacture to use pilot proportional control technology in crawler cranes, and currently offers a full range of products from 35ton to 4000ton, XCMG’s XGC88000 is the largest-tonnage model of crawler crane.

XCMG Crawler crane QUY55

Item		Unit	Parameter
Max. rated lifting capacity	Basic boom	t	55
	Fixed jib	t	5
Max load moment		KN.m	1994
Boom length		m	13～52
Boom luffing angle		°	-3～80
Fixed jib length		m	9.15～15.25
Max. single line speed for hoist mechanism (no load, at 5th layer )		m/min	121
Max. single line speed for boom luffing mechanism(at 1st layer)		m/min	52
Max. swing speed		r/min	1.5
Max. travel speed		km/h	1.35
Gradeability		%	40
Average ground pressure		MPa	0.069
Engine power		kW	125/158
Overall weight(main lifting hook，13m boom)		t	48.5
Max. single unit weight for transportation		t	31
Max. single unit dimensions for transportation(L×W×H)		m	11.5×3.47×3.4
