Max lifting capacity: 25t
Engine type:QSB6.7-C190

Advantage:
. Larger working radius, stronger lifting capacity
.Fast transferring, high operation efficiency, optimized customer benefits!

Dimension	Overall lenght		mm	11703
	Overall width		mm	2700
	Overall height		mm	3385
	Wheel base		mm	3700
	Track		mm	2200
Mass	Curb mass		kg	26365
	Axle mass	II	kg	12715
		II	kg	13650
Travelling Performance	Max. Travel speed		km/h	50
	Min. Turning radius		m	10
	Min. Ground Clearence		mm	345
	Approaching angle		°	22
	Departure angle		°	19
	Max. Grade-ability		%	55
Engine	Model			QSB6.7-C190
	Power		kW	142
	Rotation speed		r/min	616
	Emission Standard			Off-road, Euro III
