XCMG QY20B.5

Max. rated total lifting capacity: 20T
Fully extended boom: 32.76M
Fully extended boom＋jib: 42.12M
Engine model: SC8DK260Q3  WD615.327

Detail configuration:
Wire rope
Hirschmann PAT
Heater
Full dimension cab

Advantage  20 ton truck crane, QY20B.5 XCMG:
XCMG has two types of 20t truck crane. These two types are very popular in the market.
The perfect integration of the design and structure realizes the automation of welding, which is more reliable.

Dimension	Unit	QY20B.5	XCMG QY20G.5
Overall length	mm	12400	12400
Overall width	mm	2500	2500
Overall height	mm	3300	3320
Weight
Total weight in travel	kg	26020	26020
Front axle load	kg	6900	6900
Rear axle load	kg	19120	19120
Power
Engine model		SC8DK260Q3, WD615.327	SC8DK260Q3 WD615.327
Engine rated power	kW/(r/min)	192/2200 198/2200	192/2200 198/2200
Engine rated torque	N.m/(r/min)	1100/1400 1150/1400	1100/1400 1150/1400
Travel
Max. travel speed	km/h	75	75
Min. turning diameter	m	20	20
Min. ground clearance	mm	270	275
Approach angle	°	21	16
Departure angle	°	11	13
Max. grade ability	%	35	24
Fuel consumption for 100km	L	≈35	≈35
Main performance
Max. rated total lifting capacity	t	20	20
Min. rated working radius	mm	3000	3000
Turning radius at turntable tail	m	3.385	3.385
Max. lifting torque	kN.m	860	860
Base boom	m	10.06	10.06
Fully extended boom	m	32.76	32.76
Fully extended boom+jib	m	42.12	42.12
Longitudinal outrigger span	m	4.97	4.97
Lateral outrigger span	m	5.4	5.4
Working speed
Boom lifting time	s	75	75
Boom full extension time	s	95	95
Max. swing speed	r/min	3	3
Max. speed of main winch (single rope)	m/min	100	100
Max. speed of aux. winch (single rope)	m/min	100	100
