XCMG Motor grader GR135
Our Service:
* We are 7 years supplier, have good price of XCMG Motor grader GR135 for sale.
* We supply one year guarantee for all machines.
* We also supply Shantui Bulldozer Spare Parts with good price and quick response.

For more details, specification and catalogues about Shantui Bulldozer,
please contact us, Mob. 008615862203425, Mail: [email protected]


Operating weight :11 tons ,
Moldboard : 3660×610mm,

Detailed configuration
* 6BT5.9 engine,
* XCMG driving axle ,
* XCMG air conditioner driving cabin ,
* Imported differentialmechanism .

Advantages
Full hydraulic control for moving of the blade .
Strong power, comfortable driving environment, short Turning Radius suitable for Farmland improvement, mine construction, water conservancy construction and so on .

Optional parts
* Front mouldboard ,
* Rear scarifier ,
* Shovel blade

XCMG Motor grader GR135

Basic specification
Engine model	6BT5.9
Rated power/speed	100/2200kw/rpm
Dimension(LxWxH)	8015×2380×3050mm
Operating weight(Standard)	11000kg
Performance specification
Travelling speed ,forward	5、8、13、20、30、42km/h
Travelling speed ,reverse	5、13、30km/h
Tractive force(f=0.75)	61.3KN
Max. gradeability	20%
Tire inflation pressure	300kPa
Working hydraulic pressure	16MPa
Transmission pressure	1.3～1.8MPa
Operating specification
Max. steering angle of front wheels	±49°
Max. lean angle of front wheels	±17°
Max. oscillation angle of front axle	±15°
Max. oscillation angle of balance box	16
Frame articulation angle	±27°
Min. turning radius using articulation	6.6m
Blade
Maximum lift above ground	410mm
Maximum depth of cutting	535mm
Maximum blade position angle	90°
Blade cutting angle	28°—70°
Circle reversing rotation	360°
Moldboard width X height	3660×610mm
