Parameters
Bucket capacity 1.2 CBM (standard)
Operating weight:25500kgs
Max digging height:9662mm
Max digging reach:10240mm

Detail configuration
ISUZU BB-6BG1TRP engine ,128.5/2150 kw/rpm,
Hydraulic system

Advantages
Our product adopts the humanized design which results in an easy operation and maintenance.
The excavator is of low fuel consumption, low noise and low emission with ISUZU engine.

 Optional parts
Travelling alarm
Rotary warning lights fence

Model		Unit	XE265C
Operating weight		kg	25500
Standard bucket capacity		m³	1.2
Engine	Engine Model	/	ISUZU CC-6BG1TRP
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	√
	Air to air intercooler	/	√
	No. of cylinders	/	6
	Rated power/speed	kw/rpm	128.5/2100
	Max. torque/speed	N.m	637/1800
	Displacement	L	6.494
The main performance	Travel speed	km/h	5.9/4.0
	Swing speed	r/min	11.3
	Max. gradeability	/	≤35
	Ground pressure	kPa	50.1
	Max.Bucket digging force	kN	161
	Max.arm crowd force	kN	125
	Max.traction force	kN	194
Hydraulic system	Main pump	/	2 Plunger pump
	Rate flow of main pump	L/min	2×256
	Max pressure of prime relief valve	MPa	34.3/37
	Max pressure of travel system	MPa	34.3
	Max pressure of swing system	MPa	28
	Max pressure of pilot system	MPa	3.9
Oil capacity	Fuel tank capacity	L	400
	Hydraulic tank capacity	L	240
	Engine lubrication	L	25
Overall dimensions	A Overall length	mm	10160
	B Overall width	mm	3190
	C Overall height	mm	3100
	D Overall width of upperstructure	mm	2830
	E Track length	mm	4640
	F Overall width of undercarriage	mm	3190
	G Crawer width	㎜	600
	H Track length on ground	mm	3842
	I Crawer gauge	mm	2590
	J Clearance under counter weight	mm	1100
	K Ground clearance	mm	485
	L Min.tail swing radius	mm	2985
Working range	A Max. digging height	mm	9662
	B Max. dumping height	mm	6810
	C Max. digging depth	mm	6895
	D 8inch horizonal digging depth	mm	6750
	E Max. vertical wall digging depth	mm	5480
	F Max. digging reach	mm	10240
	G Min. swing radius	mm	3850
	Angle of arm deflection	Degree
