Detailed configurations
Distributing valve
Concrete conveying cylinder
Hopper

Advantages
1 year  warranty
S pipe valve
Strict quality control

Model			HBTS60-13-90	HBTS60-16-110
Theoretical conveying volume	High pressure	m3/h	43	45
	Low pressure	m3/h	74	75
Max. conveying pressure	High pressure	MPa	12.5	15.7
	Low pressure	MPa	7.3	9.2
Distribution valve type			S pipe valve	S pipe valve
Rated power		kW	90	110
Concrete conveying cylinder	Diameter	mm	200	200
	Stroke	mm	1800	1800
Hopper	Volume	L	500	500
	Feeding height	mm	1375	1375
Internal diameter of conveying pipe		mm	φ125	φ125
Pumpable concrete specification	Slump	mm	80~230	80~230
	Aggregate size	mm	≤40	≤40
Dimension L×W×H		mm	6440×2060×2150	6440×2060×2150
Overall weight		kg	6300	6400
