Detailed configurations
Internal brand hydraulic system
Sinotruck chassis
Water supply

Advantages
Stable water supply
Advanced technology in manufacturing
International brand oil pump




Type	Model	Unit	G16SX
Performance of mixing drum	Geometric volume	m³	24.9
	Mixing volume	m³	16
	Maximum diameter of drum body	mm	2432
	Length of mixing drum	mm	7273
	Angle of inclination	°	9.5
	Rotating speed	r/min	0～14
	Charge speed	m³/min	≥3
	Discharge speed	m³/min	≥2
	Residue ratio of discharge	%	＜0.7
	Range of slump	cm	5～21
Hydraulic system	Oil pump		international brand
	Motor		international brand
	Reduction gears		international brand
	Hydraulic circuit		Closed-type
Water supply	water tank capacity	L	450
	Way of water supply		Pneumatic
Complete machine	Brand of chassis		XCQC
	Chassis model		SX5315GJBJT346
	Type of driving		Left-hand drive
	Curb weight	kg	17000
	maximum gross weight	kg	31000
	Type of drive		8×4
	Wheel base	mm	1800+3375+1400
	Tyre		12.00R20
	Means of power takeoff		Power takeoff by flywheel
	Notice model		XZJ5310GJB2
	External dimensions	(length×width×height)mm	11910×2500×3995
Engine	Model		WP10.375/WP10.380E32
	Rated power	Kw/r/min	276
	Displacement	L	9.726
	Emission standard		GB III
