Detailed configuration
Cage size: 3 X 1.3 X 2.5m

Advantages
Safety protection devices equipped
Special design give solid cage structure


Brand	Focus
Item	SC200
Pay-load capacity(per cage)(kg)	2000
Lifting speed(m/min)	0-33; 0-45; 0-63, 0-96m/min
Max lifting height(m)	150m
Power supply voltage/frequency	380V/50HZ; 440V/60HZ or according to local
Cage inner dimension(l*w*h)	3 X 1.3 X 2.5m
Mast section(l*w*h)(m)	0.65 X 0.65 X 1.508 m
Standard Section Height(m)	1.508 m
Number of motors/cage	3
Rated output(kw)	2x3x11
Weight of mast section(KG)	195
Transducer power (KW)	75
safety device(m/min)	1.2
