Max lifting capacity: 60t
Engine Model: QSB6.7-C260

Advantage:
XCMG RT60 is a hot type in the rough terrain crane.His special design make the machine work in the harsh environment.

Dimension	Overall lenght		mm	13150
	Overall width		mm	3180
	Overall height		mm	3750
	Wheel base		mm	4000
	Track		mm	2400
Mass	Curb mass		kg	49000
	Axle mass	II	kg	25500
		II	kg	23500
Travelling Performance	Max. Travel speed		km/h	35
	Min. Turning radius		m	6.1(four wheels), 10.5(two wheels)
	Min. Ground Clearence		mm	467
	Approaching angle		°	20
	Departure angle		°	17.5
	Max. Grade-ability		%	65
Engine	Model			QSB6.7-C260
	Power		kW	194
	Rotation speed		r/min	2200
	Emission Standard			Off-road, Euro III
