Max. rated total lifting capacity: 90T
Fully extended boom: 50.9M
Fully extended boom＋jib: 70.4M

Detail configuration:
Wire rope
Hirschmann PAT
Heater
Full dimension cab

Advantage:
The QY90K truck crane is manufactured with the rated lifting weight of 90t.
It utilizes the patented telescopic technology. XCMG devotes to satisfy customer’s all kinds of demand.

Dimension	Unit	QY90KA
Overall length	mm	14700
Overall width	mm	2800
Overall height	mm	3900
Weight
Total weight in travel	kg	53000
axle load	kg	Axle I 9000/ Axle II 9000/Axle III13000/ Axle IV 13000/Axle V 9000
Power
Engine model		superstructure TAD720VE TAD750VE Carrier WP12.430N
Engine rated power	kW/(r/min)	superstructure 174/2300 181/2300 Carrier 315/1900 superstructure 854/1400 1050/1500 Carrier 2060/1000-1400
Engine rated torque	N.m/(r/min)
Travel
Max. travel speed	km/h	80
Min. turning diameter	mm	23000
Min. ground clearance	mm	315
Approach angle	°	20
Departure angle	°	16
Max. grade ability	%	45
Fuel consumption for 100km	L	60
Main performance
Max. rated total lifting capacity	t	90
Min. rated working radius	m	3
Turning radius at turntable tail	MM	balance weight 4200 vice winch4590
Max. lifting torque	kN.m	3450
Base boom	m	13.5
Fully extended boom	m	50.9
Fully extended boom＋jib	m	70.4
Longitudinal outrigger span	m	7.505
Lateral outrigger span	m	7.1
Working speed
Boom lifting time	s	105
Boom full extension time	s	160
Max. swing speed	r/min	2
