Detailed configuration
Chassis EQ1092FJ1, NKR77PLLWCJAY. Customers can also choose other chassis.

Advantages
Good enjoyment for operators
High quality
Long life service



Model	SQ3.2ZK1	SQ3.2ZK2	Unit
Max Lifting Moment	6.72	6.72	t.m
Max Lifting Capacity	3200	3200	kg
Recommend Power Needed At Recommend Oil Flow	14	14	kw
Max Oil Flow of Hydraulic System	25	25	L/min
Rated Pressure Of Hydraulic System	22	22	MPa
Oil Tank Capacity	60	60	L
Rotation Angle	370	370
Crane Weight	1100	1200	kg
Installation Space	850	850	mm
Choice of Chassis	EQ1092FJ1；EQ1092FJ；NKR77PLLWCJAY ；DFL1120B D530；EQ1081GJ12D5；HFC1083K103R1D；EQ1092F3GJ1；EQ5121GFJ；



SQ3.2ZK1 Lifting capability diagram
Working radius (m)	2.1	4.15	5.8
Lifting capacity (kg)	3200	1400	1000



SQ3.2ZK2 Lifting capability diagram
Working radius (m)	2.1	4.15	5.8	7.3
Lifting capacity (kg)	3200	1300	950	650
