XT870 is a new type of construction machine used for loading and excavating. The most popular model of XCMG.
* Equipped with Weichai Deutz engine, Cummins engine.
* Side swing digging device with “H” type out rigger.
* 4*2 or 4*4 driving
* Italy imported torque converter
* Optional: 4 in 1 bucket, Soonsan and Chinese brand hydraulic hammer, clamping device, etc.

XT870H
Driving style		4*2(standard) / 4*4(optional)
Digging work device		Side sway (“H” type outrigger)
Overall Weight		9000kg
Overall Dimensions(LXWXH)		6175*2350*3500mm
Engine	Model	Weichai Deutz TD226B-4Ig2/ Cummins B4.5(Euro II)/ Cummins QSB4.5(Euro III)
	Power	70kw / 74kw / 82kw
	Rated speed	2200r/min
Loading mechanism	Bucket Capacity	1.0 m3
	Bucket load	2.5t
	Dumping Height	2770mm
	Dumping reach	705 mm
	Max. breakout	66KN
	Boom lifting time	<=5s
	Total cycle time	<=10s
	System pressure	24KN
Excavating mechanism	Digger capacity	0.2 m3
	Max. digging depth	4250 mm
	Max. digging radius	5500mm
	Max.digging force	51KN
	System pressure	24KN
Max.travel speed		>=40km/h
Max. gradient		>=20
Min.turning radius		3350mm
Wheel base		2180mm
Max. Traction force		>=70KN
