Operating weight :16 tons ,
Moldboard :4270×610mm,

Detailed configuration
* 6CTA8.3 engine,
* XCMG driving axle ,
* XCMG air conditioner driving cabin ,
* Imported differentialmechanism .

Advantages
Soft chair and safety belt make the driving cabin more comfortable and safety.
Adopt durable hydraulic parts .Better working performance than other brand.
Full hydraulic control for moving of the blade .Most popular model by recent years .

Optional parts
* Front mouldboard
* Rear scarifier
* Shovel blade
*Configuration for low temperature area

Basic specification	GR215	GR215A
Engine model	6CTA8.3	6CTA8.3
Rated power/speed	160kW/2200rpm	160kW/2200rpm
Dimension(LxWxH)	8970×2625×3470mm	9180×2625×3300mm
Operating weight(Standard)	16500kg	16100kg
Performance specification
Travelling speed ,forward	5、8、11、19、23、38 km/h	5、8、11、19、23、38 km/h
Travelling speed ,reverse	5、11、23 km/h	5、11、23 km/h
Tractive force(f=0.75)	82KN	82KN
Max. gradeability	20%	20%
Tire inflation pressure	260 kPa	260 kPa
Working hydraulic pressure	16 MPa	16 MPa
Transmission pressure	1.3～1.8MPa	1.3～1.8MPa
Operating specification
Max. steering angle of front wheels	±50°	±17°
Max. lean angle of front wheels	±17°	±15°
Max. oscillation angle of front axle	±15°	15
Max. oscillation angle of balance box	15	±27°
Frame articulation angle	±27°	7.3m
Min. turning radius using articulation	7.3m
Blade
Maximum lift above ground	450mm	500mm
Maximum blade position angle	90°	28°—70°
Circle reversing rotation	360°	360°
Moldboard width X height	4270×610mm	4270×610mm
