Detailed configurations
Benz chassis
National III

Advantages
1 year  warranty
Better driving environment
Strict quality control


Item	Unit	Specification
Travelling specification
Chassis
Model		Actros4141
Manufacturer		BENZ
Wheel base	mm	2020+4280+1350
Engine
Rated power	kW/(r/min)	300/1800
Emissions standards		National III
Working performance
Pumping system
Theoretical output(High/Low)	m3/h	120/170
Delivery pressure(High/Low)	MPa	12/8
Theoretical delivery cycles(High/Low)	times/min	18/27
Transport cylinder inner diameter×travel	mm	φ260×2200
Filling height	mm	1480
Placing system
Structural style		7RZ
Placing boom Max. reach height/depth/radius	m	53/37.3/48.3
Placing boom slewing angle	°	±270
Others
High and low voltage switching mode		Automatic
