70T Truck Crane XCT70E&QY70K-I

XCMG QY70K-I

Max. rated total lifting capacity: 70T

Fully extended boom: 45M 44.5M

Fully extended boom＋jib: 61M 59.5M

Detail configuration:

Wire rope

Hirschmann PAT

Heater

Full dimension cab

Advantage:

XCMG 70 ton truck crane is the large truck crane in the market.

It makes the most complete safety device system in the industry, ensuring the lifting safer and more reliable.

Customers are satisfied with the energy, tire and so on.

XCMG QY70K has upgraded to XCMG QY70K--I.

We could satisfy all you demand.

Dimensions	Unit	XCT70E	XCMG QY70K-I
Overall length	Mm	14155	13930
Overall width	Mm	2800	2800
Overall height	Mm	3675	3575
Weight
Dead weight in travel state	Kg	44490	43000(without 1t vice counterweight)
1st.2nd axle load	Kg	9245	17000
3rd.4th axle load	Kg	26000	26000
Power
Carrier engine		WD615.338	WD615.338(domestic III)
Engine rated output	Kw(r/min)	276/2200	276/2200
Travel			1500/1400
Max.travel speed	Km/h	80
Min. turning diameter	M	24	80
Min. ground clearance	Mm	324	24
Approach angle	。	21	327
Departure angle	。	14	19
Max. gradeability	%	40	13
Fuel consumption of per 100km	L	45	40
Lifting performance			45
Max. total rated lifting capacity	T	70
Min. rated working radius	M	3	70
Turning radius at swing table tail	Mm	3857	3000
Base boom max. load moment	Kn.m	2676	3.55
Base boom	M	11.8	11.6
Full-extend boom	M	45	44.5
Full-extend boom+Jib	m	61	59.5
Outrigger longitudinal distance span	M	6.1	6.1
Outrigger lateral distance span	M	7.3	7.3
Working speed
Boom elevating time	S	60	60
Boom telescoping time	S	150	150
Max. slewing speed	r/min	2	2
Main winch max. speed(single line)	m/min	130	130
Auxiliary winch max.speed(single line)	m/min	108	108
