XCMG Truck crane QY130K

Max. rated total lifting capacity: 130T

Detail configuration:
Wire rope
Hirschmann PAT
Heater
Full dimension cab

Advantage
XCMG QY130K-I Truck Crane lifting capacity is 130t. We could arrange delivery in 20 to 30 days. Our production capacity is very large to meet customer’s requirement.


Our Service:
* We are 7 years supplier, have good price of XCMG Truck crane QY130K  for sale.
* We supply one year guarantee for all machines.
* We also supply Shantui Bulldozer Spare Parts with good price and quick response.

For more details, specification and catalogues about Shantui Bulldozer,
please contact us, Mob. 008615862203425, Mail: [email protected]


XCMG Truck crane QY130K

Classificatory	Item		Unit	Parameter
Outline dimension	Overall length		mm	14950
	Overall width		mm	3000
	Overall height		mm	3950
	Axle base	Axle 1, Axle 2	mm	1420
		Axle 2, Axle 3	mm	2420
		Axle 3, Axle 4	mm	1875
		Axle 4, Axle 5	mm	1350
		Axle 5, Axle 6	mm	1400
	Wheel base		mm	2610/2307
Mass	Total mass in travel state		kg	62000
	Axle load	Axle 1, Axle 2	kg	8800/8800
		Axle 3, Axle 4	kg	9200/12700
		Axle 5, Axle 6	kg	12700/9800
Power	Crane superstructure engine	Rated power	kw/(r/min)	162/2100
		Rated torque	N.m/(r/min)	854/1400
		Rated speed	r/min	2100
	Crane carrier engine	Rated power	kw/(r/min)	390/1800
		Rated torque	N.m/(r/min)	2400/1080
		Rated speed	r/min	2000
Travel performance	Travel speed	Max. travel speed	km/h	70
		Min. stable travel speed	km/h	2.1
	Min. turning diameter		m	24
	Min. ground clearance		mm	275
	Approach angle		(°)	23
	Departure angle		(°)	14
	Braking distance (at 30km/h)		m	≤ 10
	Max. grade-ability		%	40
	Fuel consumption for 100km		L	80
