XCMG Truck crane QY160K

Max. rated total lifting capacity: 160T
Fully extended boom: 58M
Fully extended boom＋jib: 76.1M
Engine model: OM460LA.E3A/1

Detail configuration:
Wire rope
Hirschmann PAT
Heater
Full dimension cab

Advantage:
XCMG 160K is the largest truck crane in the world. The boom length is very long and the lifting capacity is 160t. Customer could choose to be equipped with 28m jib boom which increase the working efficiency.


Our Service:
* We are 7 years supplier, have good price of XCMG Truck crane QY160K  for sale.
* We supply one year guarantee for all machines.
* We also supply Shantui Bulldozer Spare Parts with good price and quick response.

For more details, specification and catalogues about Shantui Bulldozer,
please contact us, Mob. 008615862203425, Mail: [email protected]

XCMG Truck crane QY160K


Dimension	Unit	QY160K
Overall length	mm
Overall width	mm
Overall height	mm
Weight
Total weight in travel	kg	54900
Front axle load	kg
Rear axle load	kg
Power
Engine model		OM460LA.E3A/1
Engine rated power	kW/(r/min)	360/1800
Engine rated torque	N.m/(r/min)
Travel
Max. travel speed	km/h	80
Min. turning diameter	m	26
Min. ground clearance	mm	300
Approach angle	°	20
Departure angle	°	14
Max. grade ability	%	40
Fuel consumption for 100km	L	75
Main performance
Max. rated total lifting capacity	t	160
Min. rated working radius	mm
Turning radius at turntable tail	m
Max. lifting torque	kN.m	5253
Base boom	m
Fully extended boom	m	61.4
Fully extended boom+ jib	m	88.6
Longitudinal outrigger span	m	7.8
Lateral outrigger span	m	8
Working speed
Boom lifting time	s
Boom full extension time	s
Max. swing speed	r/min	1.8
Max. speed of main winch (single rope) (no load)	m/min	110
Max. speed of aux. winch (single rope) (no load)	m/min
