Detailed configuration
Model of chassis: DGY-20D
Model of engine: STEYR WD10G

Advantages
Suitable for different working conditions .
Adopt special chassis and track roller .



Max. lifting capacity		20000kg
lifting capacity with jib		3000kg
Max. lifting moment at min .load overhang		239KN.m(196KN*1.22m)
Max. lifting moment at max .load overhang		188KN.m(41.2KN*5.50m)
Max. lifting height of the hook boom		4.2
Boom length		6.0m
Length of jib		3.0m
Hoisting speed(six part line)		10m/min
Boom elevating time		30s
Model of chassis		DGY-20D
Model of diesel engine		STEYR WD10G
Rated power		128kw/185rpm
Temperature of surroundings		-20°C-+40°C
Model of oil hydraulic pump		P5100-F63NG
Rated working pressure of system		20000kPa/2900psi
Lifting winch		Hydraulic driven , Planetary transmission
Lifting winch		Hydraulic driven , Planetary transmission
Model of Alternator		STAMFORD UC274G24
Model of are welding equipment		Lincoln DC-400 or Panasonic YM-350RF2
Model of compressor (recommended)		W-0.8/1.6
Overall dimension (L*W*H)	With boom	5.428*4.33*8.55m
	Without boom	5.428*3.24*3.20m
Operating weight		23700kg
