Detailed configuration
Model of engine: Cummins NTA855-C280

Advantages
Equip with long boom for about 7.5 meters.
Special design to protect the pipe layer turn over .


Type	SP45Y
Engine Model	Cummins NTA855-C280
Rated power & revolution (kw/rpm)	169/2000
Max.lifting weight(t)	45
Operating weight(kg)	33000
L x W xH(mm)	4750*3700*2360
Min.turning radius(mm)	3200
Track gauge (mm)	2250
Ground length(mm)	3050
Track shoes width(mm)	610(780)
Ground Pressure(Mpa)	0.086(0.070)
Mas.lifting height(mm)	5250   7210(7500)
Boom swing amplitude (m)	1.2-6.65
Hook speed (m/min)	0-6.0
Boom length(m)	6.5(7.5)
