Detailed configuration
Model of chassis: DGY-70
Model of engine: CUMMINS NT855-C360

Advantages
Easy for maintain and operation ,Suitable for different working conditions .
Top brand engine offers enough power to meet the working needs.


Lifting capacity at tipping point			70000kg
Max. lifting moment at min .load overhang			836KN.m(686KN*1.22m)
Max. lifting moment at max .load overhang			650KN.m(100KN*5.50m)
Boom length			7.0m
Max. lifting height of the hook			5.37m
Hoisting speed(six part line)			6m/min
Boom elevating time			6s
Model of chassis			DGY-70
Model of diesel engine			CUMMINS NT855-C360
Rated power			239kw/320HP
Model of oil hydraulic pump			CBY4100/2040
Rated working pressure of system			20000kPa/2900psi
Lifting winch		Hydraulic driven , Planetary transmission, Free-fall function
Diameter of lifting wire rope			@22mm
Length of lifting wire rope			60m
Ranging winch			Hydraulic driven , Planetary transmission
Diameter of ranging wire rope			@22mm
Length of ranging wire rope			80m
Temperature of surroundings			-20°C- +40°C
Overall dimension (L*W*H)	With boom		5.7*4.85*7.82m
	Without boom		5.7*4.85*7.82m
Ground pressure	Without load		92kPa
Operating weight			51000kg
