Detailed configuration
Model of engine: NTA855-C360S10

Advantages
Rated power 235 Kw offer enough power for the pipe layer .
Easy for maintain , easy for operation .


Engine		NTA855-C360S10
Rated power	kW/rpm	235/2000
Ma×imum lifting weight	t	70
Operating weight	kg	47500
L×W×H	mm	5560×3700×3395
Minimum turning radius	mm	3950
Track gauge	mm	2380
Ground length	-	3620
Track shoe width	mm	760
Ground pressure	MPa	0.086
Ma×imum lifting height	mm	6550 8150(9.0m Boom)
Boom swing amplitude	m	1.2–7.2 1.2–8.8(9.0 Boom)
Hook speed	m/min	0–6.0
Boom length	m	7.3(9.0 Optional)
